Everest | Ultrasonic Cleaning
MultiClean
An ultrasonic washing system designed for the cleaning of sensitive parts.
Is this system right for you?
Let our expert team guide you in choosing the perfect system for your needs.
MultiClean multi tank ultrasonic washing systems are designed for the cleaning of sensitive parts in the production and maintenance lines of all sectors. Effectively used in the precision cleaning of the smallest holes and sections of all kinds of parts in production, maintenance and repair lines before surface treatment or final assembly. In MultiClean washing systems, effective and sensitive cleaning is performed with pre-washing, ultrasonic washing, rinsing, extra-rinsing and drying processes based on part contamination. In the MultiClean washing system, where multi-tank cleaning takes place, 28kHz ultrasonic is offered as standard located at the tank floor depending on the tank volume.
Washing system: Multistage ultrasonic washing system
Working principle: The parts are placed into baskets and cleaned in pre-washing, ultrasonic washing, rinsing, passivation (optional), drying, vacuum drying (optional) stages.
Tank system: multi-boiler with individually heating
Construction: Entirely from 304 stainless steel
Ultrasonic: 28kHz as standard. 40kHz available at request.
Elevate your standards with Everest Ultrasonic cleaning systems.
Features
- Space saving
- Costs saving
- Environmentally friendly
- Energy efficient
- Suitable for light to medium weight items up to 40kg as standard
- Manual installation and basket transfer as standard
- Designed for delicate cleaning applications
- At low liquid level protection which stops the machine
- Cleaning time and temperature are adjustable
- Automatic loading and unloading basket transfer system can be integrated (optional)
- Pneumatic loading and unloading basket transfer system can be integrated (optional)
- Can be integrated into the serial production line (optional)
| MultiClean Options | |||
| Model | Basket Size (L/W/H)mm | External Size (L/W/H)mm | Tank Capacity lt |
| MultiClean 2-60 | 450*250*350 | 1650*600*900 | 60 |
| MultiClean 2-80 | 560*280*350 | 1900*630*900 | 80 |
| MultiClean 2-120 | 560*450*350 | 1900*800*900 | 120 |
| MultiClean 2-160 | 800*450*350 | 2350*800*900 | 160 |
| MultiClean 2-240 | 800*680*350 | 2350*1050*900 | 240 |
| MultiClean 3-60 | 450*250*350 | 2300*600*900 | 60 |
| MultiClean 3-80 | 560*280*350 | 2670*630*900 | 80 |
| MultiClean 3-120 | 560*450*350 | 2670*800*900 | 120 |
| MultiClean 3-160 | 800*450*350 | 3350*800*900 | 160 |
| MultiClean 3-240 | 800*680*350 | 3350*1050*900 | 240 |
| MultiClean 4-60 | 450*250*350 | 2950*600*900 | 60 |
| MultiClean 4-80 | 560*280*350 | 3450*630*900 | 80 |
| MultiClean 4-120 | 560*450*350 | 3450*800*900 | 120 |
| MultiClean 4-160 | 800*450*350 | 4400*800*900 | 160 |
| MultiClean 4-240 | 800*680*350 | 4400*1050*900 | 240 |
| MultiClean 5-60 | 450*250*350 | 3600*600*900 | 60 |
| MultiClean 5-80 | 560*280*350 | 5170*630*900 | 80 |
| MultiClean 5-120 | 560*450*350 | 5170*800*900 | 120 |
| MultiClean 5-160 | 800*450*350 | 5400*800*900 | 160 |
| MultiClean 5-24 | 800*680*350 | 5400*1050*900 | 240 |
Elevate your standards with Everest Ultrasonic cleaning systems.
The Everest Ultrasonic Cleaning Systems range includes advanced models designed for efficient, deep cleaning of electronic components, precision tools, and industrial parts. Harnessing ultrasonic waves, Everest systems effectively remove contaminants, oils, and residues, reaching areas that traditional cleaning methods cannot access. Ideal for intricate assemblies and complex machinery, these systems ensure that even the smallest crevices are thoroughly cleaned, extending the life and reliability of critical components.
What sets Everest apart is its dedication to engineering excellence, durable materials, and continuous support. Partnering with Etek Europe, our clients benefit from expert consultation, experienced technicians, and ongoing support. At Etek Europe, we’re more than a supplier—we’re your partner in achieving superior cleanliness, efficiency, and operational longevity.
