AutoClean ultrasonic automotive washing systems are designed for sensitive cleaning of engines and engine components for the automotive, marine, railway, and aviation industries. Before surface treatment or final assembly, in production, maintenance, repair lines; these systems are widely used in precision cleaning of all kinds of parts such as engines, engine blocks, cylinder heads, injectors, brake discs, gearboxes and radiators. AutoClean washing systems are tens of times more effective than conventional hand washing. Due to ultrasonic cleaning in AutoClean washing systems, the smallest holes and sections are effectively reached, and an effective cleaning is done. In the AutoClean washing system, where ultrasonic washing takes place in a single tub, it is offered as 28kHz or 40kHz ultrasonic standard on the sides or on the bottom, depending on the volume and tank geometry.
Everest | Ultrasonic Cleaning
AutoClean
An ultrasonic washing system designed for the cleaning of sensitive parts.
Please complete all fields below to download the datasheet.
Is this system right for you?
Let our expert team guide you in choosing the perfect system for your needs.
AutoClean ultrasonic automotive washing systems are designed for sensitive cleaning of engines and engine components for the automotive, marine, railway, and aviation industries. Before surface treatment or final assembly, in production, maintenance, repair lines; these systems are widely used in precision cleaning of all kinds of parts such as engines, engine blocks, cylinder heads, injectors, brake discs, gearboxes and radiators. AutoClean washing systems are tens of times more effective than conventional hand washing. Due to ultrasonic cleaning in AutoClean washing systems, the smallest holes and sections are effectively reached, and an effective cleaning is done. In the AutoClean washing system, where ultrasonic washing takes place in a single tub, it is offered as 28kHz or 40kHz ultrasonic standard on the sides or on the bottom, depending on the volume and tank geometry.
Washing system: Large ultrasonic washing systems
Working principle: Parts placed on the standard floor mounted platform by hand or with the assistance help of an overhead crane are cleaned by ultrasonic washing.
Tank system: Single tank with heating
Construction: Entirely from 304 stainless steel
Ultrasonic: 28 or 40kHz
Elevate your standards with Everest Ultrasonic cleaning systems.
Features
- Â Space saving
- Cost saving
- Environmentally friendly
- Energy efficient
- Suitable for heavy items
- Manual installation
- Designed for delicate cleaning.
- Low water liquid level protection which stops the machine automatically
- Cleaning time and temperature are adjustable
- Can be integrated into the serial production line (optional)
| AutoClean options | |||||
| Model | Maximum Loading Height mm | Tank Size L/W/H)mm | External Size L/W/H)mm | Tank Volume Lt | Loading Weight Kg |
| AutoClean 200 | 300 | 890*430*490 | 1450*924*1100 | 200 | 75 |
| AutoClean 300 | 400 | 890*550*630 | 1530*1190*1170 | 300 | 250 |
| AutoClean 400 | 400 | 1180*650*650 | 1830*1290*1170 | 500 | 250 |
| AutoClean 600 | 450 | 1330*750*700 | 1980*1390*1220 | 680 | 250 |
| AutoClean 800 | 650 | 1330*750*900 | 1980*1390*1420 | 960 | 500 |
| AutoClean 1000 | 350 | 1580*800*890 | 2650*1440*1280 | 1200 | 500 |
| AutoClean 1300 | 900 | 1580*800*1200 | 2750*1440*1580 | 1580 | 500 |
| AutoClean 2000 | 900 | 1850*950*1200 | 3000*1600*1580 | 2100 | 900 |
| AutoClean 3000 | 1000 | 2100*1100*1300 | 3250*1750*1700 | 3100 | 900 |
| AutoClean 4500 | 1000 | 2700*1450*1300 | 3900*2100*1700 | 5000 | 900 |
| AutoClean 6000 | 1000 | 3200*1600*1300 | 4400*2250*1700 | 6600 | 1500 |
| AutoClean 9000 | 1200 | 3700*1700*1500 | 4800*2400*1900 | 9300 | 1500 |
Features
Washing steps
- The entire process takes place in a single tank.
Addable Features
- Dual and multi frequency ultrasonics available at request
- AISI 316L or AISI 316T stainless steel can be used
- Oil separation
- Pump filtration
- Automatic water filling/draining
- Pump circulation
- Chemical dosing systems
- Pneumatic oscillating platform
- Other system features
Elevate your standards with Everest Ultrasonic cleaning systems.
